Satellite terminal
Montrans M-5 LTE
MONTRANS M-5 LTE with external antennas combines the advanced features and technologies of the 5x line of terminals: CAN Scanner, Exigner Driver App, support for two CAN buses, RS 485, RS 232, Modbus, 1-Wire, Bluetooth and high data rate and ultra-low power consumption thanks to LTE connectivity with global coverage.
Modifications of M-5 satellite terminals
GPS/GLONASS terminal Montrans M-5 LTE
MONTRANS M-5 LTE combines advanced technologies of GPS/GLONASS monitoring Easy Logic and CAN-Scanner.
The terminal allows you to work with the main standards of cellular communication 2G / LTE (2G/3G/4G), with 2 CAN-buses simultaneously, transmit data from sensors and devices by supporting protocols RS 485, RS 232, 1-Wire and via Bluetooth 5.0. Tracker modifications with external and internal antennas are available.
The terminal allows you to work with the main standards of cellular communication 2G / LTE (2G/3G/4G), with 2 CAN-buses simultaneously, transmit data from sensors and devices by supporting protocols RS 485, RS 232, 1-Wire and via Bluetooth 5.0. Tracker modifications with external and internal antennas are available.
GPS/GLONASS terminal Montrans M-5 WiFi
A distinctive feature of the on-board vehicle monitoring system Montrans M-5 Wi-Fi is offline operation with the ability to transmit information via Wi-Fi and create an access point to receive data from other terminals to send to the server, to the vehicle monitoring system.
It is designed to work on hard-to-reach objects, in places with poor cellular communication, or with a complete lack of GSM coverage. This allows to reduce the cost of specialized equipment, in particular, expensive satellite communication.
It is designed to work on hard-to-reach objects, in places with poor cellular communication, or with a complete lack of GSM coverage. This allows to reduce the cost of specialized equipment, in particular, expensive satellite communication.
GPS/GLONASS terminal Montrans M-5
The optimal configuration of this tracker will cover most needs in satellite transportation monitoring. Thanks to external GLONASS/GPS and GSM antennas, the terminal provides a wide range of readings with a high degree of accuracy.
- External GLONASS/GPS and GSM antennas
- Built-in Li-Po battery 800 mA/h
- 2G-modem
- 2 SIM-cards
- Support SD-cards with memory up to 32 GB
- 6 universal input lines
- 4 control output lines
- Interfaces: RS-232, RS-485, CAN and 1-Wire
- MODBUS support
- Bluetooth 4.0
From basic transportation monitoring to business automation
The terminal is equipped with 4 GB eMMC internal memory and can solve complex tasks in the field of vehicle monitoring, driving style and fuel consumption control, as well as fleet and stationary objects automation. You can automatically control central locking, vehicle engine and headlights, create polygonal geofences and control speed limits in each, and adjust light, temperature and humidity levels based on sensor readings. All of these capabilities are enabled through the use of Easy Logic technology.
The Montrans M-5 LTE terminal is designed for:
✔ Monitoring the condition of the vehicle
✔ Monitoring its location and movements
✔ Monitoring mileage and fuel consumption
✔ Motor hour counting
✔ Driving style detection (EcoDriving)
✔ Accident event detection
✔ RFID tag readers
✔ Temperature monitoring
✔ Monitoring its location and movements
✔ Monitoring mileage and fuel consumption
✔ Motor hour counting
✔ Driving style detection (EcoDriving)
✔ Accident event detection
✔ RFID tag readers
✔ Temperature monitoring
More options for working with the CAN bus
MONTRANS M-5 LTE is capable of simultaneously receiving data from two CAN-buses. The terminal can decode more than 13,000 parameters from the CAN bus using the J1939 protocol, which saves time when searching for the necessary information about the vehicle's condition. It also supports the standard FMS and J1979 protocols.
Built-in monitoring technologies
Accelerometer
+
Archive size
up to 170,000 points
Remote configuration
+
GSM jamming detection
+
Parallel data transfer to two servers
+
Notifications to the driver
+
Modbus support
+
Autoinformer
+
Voice communication
+
Geofences
+
Eco Driving
+
CAN Scanner
+
Terminal interfaces
Analog sampled and pulse-frequency inputs
Six
Transistor outputs
Four
Digital inputs RS 485
One
1-Wire digital inputs
One
CAN inputs
Two
RS 232
One
Output
Maximum voltage
30 V
Maximum current
200 mA
Output type
Transistor
CANBUS
Protocols
J1939, FMS, J1979, OBD-II
Identifiers
29 and 11 bit
Power supply
Li-Ion rechargeable battery
600 mAh
Operating supply voltage
9-39 V, Polarity protection
Average power consumption
0,54 W
Protection against polarity reversal and impulse surges
+
